RG Competition Floor "Beijing", 14 x 14 m, savanne-beige
Official RG floor at the Olympic Games in Beijing 2008 and Tokyo 2020!
FIG-certified.
The floor consists of an underlay construction with 144 individual plates with special foam elements for high elasticity: 100 plates each 124x124 cm, 40 plates each124 x 62cm and 4 plats each 62 x 62 cm. 121 special wooden plates are covering on top held together by velcro. Extremely smooth RG Super Velours carpet with great fatique resistance, good noise damping and antistatic due to carbon fibres, consisting of 3 rolls each 14x4 m and one roll 14x2 m, red glue tape to mark the competition area of 13x13 m. Colour of carpet: savanne-beige.
RG-Competition Floor "Beijing", 16x16 m
Official RG-floor of Olympic Games Beijing 2008 !
Size 16 x 16m.
The floor consists of an underlay construction with 144 individual plates with special foam elements for high elasticity: 100 plates each 124x124 cm, 40 plates each124 x 62cm and 4 plats each 62 x 62 cm. 121 special wooden plates are covering on top held together by velcro. Extremely smooth RG Super Velours carpet with great fatique resistance, good noise damping and antistatic due to carbon fibres, consisting of 4 rolls each 16x4 m, red glue tape to mark the competition area of 13x13 m. Colour of carpet: savanne-beige
Elastic Swing Floor "Moscow"- partially assembled
Variants:
Schwingboden "Moskau" 14x14 m - teilmontiert
FIG-certified, ORIGINAL REUTHER
Top competition free exercise swing floor with a new Spring & Security System that causes a maximum rebound effect.
Sub-construction made of 15 mm high waterproof plywood sections:
50 sections 120x240 cm, 20 sections 100 x 240 cm and 4 sections 100 x 100 cm.
The underconstruction is equipped with 2.336 high quality tempered steel springs.
The covering mat system is composed by:
196 puzzle shaped foam plates (50 mm high) and
7 floor mats 14x2 m x 20 mm made by special high quality foam covered with needle fleece (20 mm high).
Mats are linked together by 6 “Duo Velcro” straps.
Including 4 white straps for marking the competition area of 12x12 m.
Total surface: 14x14 m
Height: 20 cm
Rollable Mat "Flexi-Roll" 20 x 2 m, 40 mm
Variants:
Rollable Mat "Flexi-Roll" 20 x 2 m, 40 mm
Size: 20 x 2 x 0,40m
PVC skirting for "Moscow" floor
Dark blue skirting to surround the swing floor. The skirting protects against dust and ensures a uniform appearance of the floor. It is attached using hook-and loop tape.
For a complete swing floor 14x14 m, 4 skirts are required.
Technical details:
Length: 14 m
Height: 20 cm
Rollable Mat "Flexi-Roll" - Area 14 x 14 m
Variants:
"FLEXI-Roll"-Fläche 14x14 m, 40 mm, spiethblau
7 rollable mats each 14 x 2 m, 40 mm
blue velcro stripe to join the mats together and white velcro stripe
to mark the competition area of 12 x 12 m
Velcro 150mm spiethblue, per meter
Variants:
Velcro 14 cm spiethblue, per meter
For covering the edges between landing mats. (1 roll = 50 running meters)
Velcro 96mm spiethblue, 14 meter
Variants:
Velcro 96mm spiethblue, 14 meter
Hook and loop tape preassembled to 14 m for connecting the Swing Floor "Moscow" rollable mats.
TECHNICAL DETAILS:
Width: 96 mm;
Length: 14 m;
Colour: spiethblue
Velcro 96mm spiethblue, per meter
Variants:
lfm. Flausch-Klettband 96 mm breit - spiethblau
Spiethblue hook and loop tape e.g. for connecting rollable mats or landing mats.
TECHNICAL DETAILS:
Width: 96 mm;
Colour: spiethblue;
Maximum length in one piece: 43 m = 1 roll
Please order in meter (If you need 12 m, please order 12 pieces)
White velcro 12m
Variants:
White velcro, 5cm 12m
For marking the 12x12m competition area on the FIG-certified 14x14m Swing Floor "Moscow".
