Variants:
Tumbling Track "Moscow" 12 m - assembled
ORIGINAL REUTHER
Same construction as Competition Free Exercise Swing floor with a new Spring & Security System that causes a maximum rebound effect.
Sub-construction made of:
10 x 15 mm high waterproof plywood sections each 200 x 120 cm
The floor is equipped with high quality tempered steel springs.
The sub-construction is covered by:
24 Puzzle shaped foam plates 100 x 100 x 5 cm high and
Rollable mat 12 x 2 m wide and 20mm high.
The layer of special high quality foam contributes to optimized rebound effects.
Total height: 20 cm
Smooth-running transport and storage trolley for mats. For 15 gymnastics mats, 11 mats (8 cm thick), 18 judo mats or 40 puzzle boards.The trolley has 4 rubber casters (ø 160 mm, 44 mm wide) that leave no marks on the floor and make the trolley easy and simple to move.The trolley also has an ergonomically shaped bracket and a heavy metal frameTECHNICAL DETAILSDimensions: 200x100 cm
Variants:
2511292 Tumbling Track "Stuttgart" 11 elements
Size per element 122 x 200 cm.
Without rollable mat!
Constructed of pressure distribution plate made of flexural elastic multilayer special plywood connected with bottom spring plate by means of velcro. Total height approx. 12,5 cm, with velcro tape on long sides to fix the rollable mats in colours spiethblue). Length upon request! We recommend to cover the base construction with SPIETH floor exercise mats “FLEXIROLL®“ or “TRIFLEX®“.
Consisting of 3 foldable landing mats, each 300x200x30 cm, blue.
Including mat cover 600x300x30 cm with the marked landing zone in yellow and additional soft mat "Happy Landing" 400x200x10 cm in yellow.
Consisting of 5 individual elements, each 200 x 100 cm. With 25 mm "Triflex" rollable mat and total height of approx. 30 cm to match the FIG-certified "SPIETHway Evolution" tumbling track. Incl. anti-slip and weight distribution elements, also suitable for installation on normal gym floors.
5 elements (10x1 m) for tumbling or optionally with 10 elements (20x1 m) for TeamGym.
Variants:
Tumbling Track "Moscow" 18 m - partially assembled
ORIGINAL REUTHER
Same construction as Competition Free Exercise Swing floor with a new Spring & Security System that causes a maximum rebound effect.
Sub-construction made of:
12 x 15 mm high waterproof plywood sections each 200 x 120 cm
The floor is equipped with high quality tempered steel springs.
The sub-construction is covered by:
36 Puzzle shaped foam plates 100 x 100 x 5 cm high and
Rollable mat 18 x 2 m wide and 20mm high.
The layer of special high quality foam contributes to optimized rebound effects.
Total height: 20 cm
Variants:
1790413 Tumblingtrack element "Stuttgart" 9 elements - partially assembled
Plywood panels connected by Velcro to lower panels with elastic foam pieces. One element is 122 cm long and 200 cm wide.
Height ca. 12,5 cm with Velcro tapes on the sides to attach a rollable mat. Delivery without rollable mat. The SPIETH rollable mats 'FLEXIROLL' or 'TRIFLEX' are recommended. Incl. assembly manual.
_TECHNICAL DETAILS:
Length: 10,98 m (9 elements);
Width: 200 cm;
Height: ca. 12,5 cm;
Colour: spiethblue
